CyberPower OL2000ERTXL2U guarantees power backup protection for IT equipment, servers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems, and surveillance systems. The UPS adopts double-conversion topology to provide high-quality power output with additional ECO Mode to conserve power and save on energy costs. This generator-compatible UPS features hot-swappable battery packs for maintenance without power interruption, and Emergency Power Off (EPO) switch to allow users to shut off UPS immediately during emergency.

To extend battery lifetime, the UPS adopts Smart Battery Management (SBM) to enhance battery charging process and achieve a lower total cost of ownership. This model also features detachable LCD display panel to relocate the panel for convenient monitoring, and RJ11/RJ45 port to provide data line protection against surges and spikes. The PowerPanel® Power Management Software allows user to perform real-time monitoring and remote management of the UPS.

• Online (Double Conversion) UPS Topology
• Generator Compatible
• Critical/Non-critical Load Outlets
• Smart Battery Management (SBM)
• Extended Battery Module (EBM)
• EMI and RFI Filtration
• LCD Status Display
• Emergency Power Off (EPO) Port
• SNMP/HTTP Remote Management Capability (Optional)
• ECO Mode
• Overload Protection
• Zero Transfer Time
• Hot-swappable Batteries
• Surge and Spike Protection
• Phone/Fax/Modem/DSL/Network Protection
• Detachable LCD Panel
• PowerPanel® Management Software
• Rack/Tower Convertible Configurations

Item requires forklift at delivery. Please confirm prior to ordering.

Phase: Single Phase

Form Factor: Rackmount, Tower

UPS Topology: Online Double Conversion

Energy Saving Technology: Online ECO Mode Efficiency > 96%

Generator Compatibility: Yes

Input Voltage Range ( Vac ): 190 - 300

Adjustable Voltage Range ( Vac ): 0-60% Load for 120 - 139 Vac | 0-70% Load for 140 - 159 Vac | 0-80% Load for 160 - 179 Vac | 0-90% Load for 180 - 189 Vac | 0-100% Load for 190 - 300 Vac

Input Frequency ( Hz ): 50 ± 10 | 60 ± 10

Input Frequency Detection: Auto-sensing

Rated Input Current ( A ): 10

Input Power Factor: 0.99

Input Connector Type: IEC C14

Detachable Power Cord Plug Type: IEC C14 x 1

Power Cord Length (m): 3

Output Capacity (Watts): 1800

On Battery Waveform: Pure Sine Wave

On Battery Voltage(s) ( Vac ): 200 ± 2% | 208 ± 2% | 220 ± 2% | 230 ± 2% | 240 ± 2%

Output Voltage Setting: Configurable

On Battery Frequency ( Hz ): 50 ± 0.5% | 60 ± 0.5%

Output Frequency Setting: Configurable

Power Factor: 0.9

ECO Mode Voltage Tolerance: ± 10 % | ± 15 %

Overload Protection: Internal Current Limiting, Circuit Breaker

Overload Protection (Line Mode): 105-125% Load for 1 min, 125-150% Load for 10 sec

Overload Protection (Battery Mode): 105-130% Load for 10 sec, 130-150% Load for 2 sec

Overload Protection (Bypass Mode): Circuit Breaker

Crest Factor: 3 : 1

Harmonic Distortion (Linear Load): THD?3%

Harmonic Distortion (Non-linear Load): THD?5%

Internal Bypass: Automatic Bypass, Manual Bypass

Outlet(s) - Total: 9

Outlet Type: IEC C13 x 8 | IEC C19 x 1

Outlet(s) - Battery & Surge Protected: 9

Outlet(s) - Critical Load (CL): 5

Outlet(s) - Non-Critical Load (NCL): 4

Typical Transfer Time ( ms ): 0

Runtime at Half Load ( min ): 20

Runtime at Full Load ( min ): 6.5

Typical Recharge Time ( Hours ): 5

Start On Battery: Yes

Smart Battery Management (SBM): Yes

Hot-swappable: Yes

Battery Type: Sealed Lead-acid

Battery Cartridge: RBP0076

RBP Quantity ( pcs ): 1

Battery Quantity (Each RBP) ( pcs ): 6

Battery Voltage (Each RBP) ( V ): 72

Compatible Extended Battery Module (EBM): BPE72V60ART2US

Max. EBM Quantity ( pcs ): 10

Surge Suppression ( Joules ): 1335

EMI/RFI Filtration: Yes

Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out

LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log

LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting, Language

LED Indicators: Power On, Line Mode, Battery Mode, Bypass Mode, Battery Capacity, Low Battery, Overload, UPS Fault, Wiring Fault, Replace Battery

HID Compliant USB Port(s): 1

Dry Contact (with Relay): Yes

Emergency Power Off (EPO) Port: Yes

Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery

Management Cable ( pcs ): Power Cord x1, USB Cable x1, Serial Cable x1, Phone Line x1

Power Management Software: PowerPanel Business (Recommended)

SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205

Enclosure Construction: Metal

Rackmount Rail: Yes

Rackmount Ears: Yes

Dimensions: 433 x 88 x 600mm

Weight: 31kg

Certifications: CE, BSMI, C-Tick
