Product Details
+
- Most suitable for automation assembly machines because it can be installed into the XY robot
- Stable torque accuracy helps uniform screw tightening for automation
- Easy to install to the existing system
- Safe and risk free low voltage DC30V
- All models have stepless torque adjustment
- RoHS compliant
Classification
- Product Group: Automation & Engineered Products
- Electric or Pneumatic: Electric
- Manual or Powered: Powered
- Low Voltage DC with Power Source or Direct Plug-in: DC
- Standard or Brushless: Standard
- ESD-Safe: No
Specifications
- Model No.: CLF-6000XH
- Drive Size: 1/4" Hex
- Drive Type: In-line
- Operation: Remote
- Torque: 3.0 to 5.3 lbf·in (3.0 to 6.0 kgf·cm) (0.3 to 0.6 N·m)
- Approximate RPM:
- 750 @ 30VDC
- 400 @ 20VDC
- Length: 9.21"
- Dia.: 1.46"
- Weight: 21.52 oz
- Screw Size (mm);
- 2.0 to 3.0 Machine Screw
- 2.0 to 2.6 Tapping Screw
